OEM#: ECP64314TR-4New OEM Original Outright
MOTOR, 60HP, 1780RPM, 3PH, 60HZ, 364T, TEFC, FOOT by BALDOR
Your price:
$19,301.26 each
OEM#: ECP64314TR-4MOTOR, 60HP, 1780RPM, 3PH, 60HZ, 364T, TEFC, FOOT by BALDOR
New OEM Original Outright
Your price:
$19,301.26 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 60HP,1780RPM,3PH,60HZ,364T,TEFC,FOOT,
Features:
Petroleum, chemical and other industries with belt driven heat exchangers requiring premium efficient motors designed to API 661 standards of 40,000 hours bearing life.
Features:
- NEMA premium efficiency
- Motors meet IEEE 841 specifications for the chemical industry and incorporate roller bearings on 210 frames and larger for heavy belt loads
- VBX / VBXX Inpro bearing isolators on both ends
- Shaft up requires removing plug in upper end and reversing drain
- Motors have RTV sealed end bracket-to-frame fits and epoxy coated rotor and stator
- Motors are inverter ready
- 5-year warranty
Petroleum, chemical and other industries with belt driven heat exchangers requiring premium efficient motors designed to API 661 standards of 40,000 hours bearing life.
Technical Specs
P/N: ECP64314TR-4 Key Specs
Item
MOTOR, 60HP, 1780RPM, 3PH, 60HZ, 364T, TEFC, FOOT
OEM
BALDOR
OEM #
ECP64314TR-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
# Of Rotor Bars
47
# Of Stator Slots
60
Ambient Temp C
40
Bearing-Drive-End
NU313
C-Dimension Inches
33.44
Country of Origin
USA
Design Code
B
Drive End Flange
Standard
Duty
Continuous
Efficiency-1
95.3
Efficiency-2
94.5
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
18.9
Fl Efficiency
95
Frame
364T
Grease
MOBILITH SHC220
Hertz
60
Horsepower
60
Ieee-Test
90DBA
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Max. Kvar
10
Motor Rpm 60Hz
1780
Mounting
Rigid
Opposite End Bearing
6313
Phase
3
Poles
4
Power-Factor
87
Rpm
1780
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
P36G3368
Type
P
Voltage
460
Weight Lbs.
902
Baldor-Reliance Motor, 60HP,1780RPM,3PH,60HZ,364T,TEFC,FOOT,
Features:
Petroleum, chemical and other industries with belt driven heat exchangers requiring premium efficient motors designed to API 661 standards of 40,000 hours bearing life.
Features:
- NEMA premium efficiency
- Motors meet IEEE 841 specifications for the chemical industry and incorporate roller bearings on 210 frames and larger for heavy belt loads
- VBX / VBXX Inpro bearing isolators on both ends
- Shaft up requires removing plug in upper end and reversing drain
- Motors have RTV sealed end bracket-to-frame fits and epoxy coated rotor and stator
- Motors are inverter ready
- 5-year warranty
Petroleum, chemical and other industries with belt driven heat exchangers requiring premium efficient motors designed to API 661 standards of 40,000 hours bearing life.
