OEM#: ECP4408TR-4New OEM Original Outright
MOTOR, 250HP, 1785RPM, 3PH, 60HZ, 449T, TEFC by BALDOR
Your price:
$53,767.28 each
OEM#: ECP4408TR-4MOTOR, 250HP, 1785RPM, 3PH, 60HZ, 449T, TEFC by BALDOR
New OEM Original Outright
Your price:
$53,767.28 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 250HP,1785RPM,3PH,60HZ,449T,TEFC
Features:
- Heavy gauge steel and cast iron frames
- Roller bearings for heavy belted loads (not suitable for coupled loads)
- ISR® (Inverter Spike Resistant®) copper windings
- Low-loss electrical grade lamination steel
- Three year warranty
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: ECP4408TR-4 Key Specs
Item
MOTOR, 250HP, 1785RPM, 3PH, 60HZ, 449T, TEFC
OEM
BALDOR
OEM #
ECP4408TR-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
C-Dimension Inches
53.24
Class Insulation
F
Country of Origin
USA
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
276
Fl Efficiency
96.2
Frame
449T
Horsepower
250
Is_Motor
yes
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Voltage
460
Weight Lbs.
2995
Baldor-Reliance Motor, 250HP,1785RPM,3PH,60HZ,449T,TEFC
Features:
- Heavy gauge steel and cast iron frames
- Roller bearings for heavy belted loads (not suitable for coupled loads)
- ISR® (Inverter Spike Resistant®) copper windings
- Low-loss electrical grade lamination steel
- Three year warranty
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
