OEM#: ECP4114T-4New OEM Original Outright
MOTOR, 50HP, 3540RPM, 3PH, 60HZ, 326TS, 1256M, TEFC, F by BALDOR
Your price:
$12,171.18 each
OEM#: ECP4114T-4MOTOR, 50HP, 3540RPM, 3PH, 60HZ, 326TS, 1256M, TEFC, F by BALDOR
New OEM Original Outright
Your price:
$12,171.18 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 50HP,3540RPM,3PH,60HZ,326TS,1256M,TEFC,F
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy gauge steel and cast iron frames
- Ball bearings
- ISR® (Inverter Spike Resistant®) copper windings
- Low-loss electrical grade lamination steel
- Three year warranty
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: ECP4114T-4 Key Specs
Item
MOTOR, 50HP, 3540RPM, 3PH, 60HZ, 326TS, 1256M, TEFC, F
OEM
BALDOR
OEM #
ECP4114T-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
C-Dimension Inches
29.15
Class Insulation
F
Country of Origin
USA
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
56
Fl Efficiency
93.6
Frame
326TS
Hertz
60
Horsepower
50
Is_Motor
yes
Phase
3
Rpm
3540
Rpm Range
3001-3600
Service Factor
1.15
Voltage
460
Weight Lbs.
610
