OEM#: CECP84104T-5New OEM Original Outright
MOTOR, 30HP, 1765RPM, 3PH, 60HZ, 286TC, 1060M, TEFC, F by BALDOR
Your price:
$9,976.74 each
OEM#: CECP84104T-5MOTOR, 30HP, 1765RPM, 3PH, 60HZ, 286TC, 1060M, TEFC, F by BALDOR
New OEM Original Outright
Your price:
$9,976.74 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 30HP,1765RPM,3PH,60HZ,286TC,1060M,TEFC,F
Features:
- Designed and manufactured and tested to exceed the IEEE 841-1994 standards for severe duty TEFC induction motors
- Premium efficiency copper windings using Baldor-Reliance ISR (Inverter Spike Resistant)® magnet wire comply with CEE efficiency guidelines
- Inpro Seal® on fan and drive end shaft extensions
- 2-part yellow epoxy oxide primer (inside & outside)
- Gray epoxy paint and corrosion resistant hardware
- Reduced noise, vibration and mechanical tolerances
- Final test and vibration results shipped with motor
Typical applications include petro-chemical, pulp and paper plants, mines and other installations requiring premium efficient motors manufactured and tested to rigid standards for severe duty service.
Technical Specs
P/N: CECP84104T-5 Key Specs
Item
MOTOR, 30HP, 1765RPM, 3PH, 60HZ, 286TC, 1060M, TEFC, F
OEM
BALDOR
OEM #
CECP84104T-5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
# Of Rotor Bars
40
# Of Stator Slots
48
Ambient Temp C
40
Bearing-Drive-End
6311
C-Dimension Inches
27.93
Country of Origin
USA
Design Code
B
Drive End Flange
C-Face
Efficiency-2
92.4
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
28
Fl Efficiency
93.6
Frame
286TC
Grease
POLYREX EM
Hertz
60
Horsepower
30
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Max. Kvar
5.8
Motor Rpm 60Hz
1765
Mounting
Rigid
Opposite End Bearing
6311
Phase
3
Poles
4
Power-Factor
87
Rpm
1765
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
10G309Y670
Temp. Code
T3
Voltage
575
Weight Lbs.
460
Baldor-Reliance Motor, 30HP,1765RPM,3PH,60HZ,286TC,1060M,TEFC,F
Features:
- Designed and manufactured and tested to exceed the IEEE 841-1994 standards for severe duty TEFC induction motors
- Premium efficiency copper windings using Baldor-Reliance ISR (Inverter Spike Resistant)® magnet wire comply with CEE efficiency guidelines
- Inpro Seal® on fan and drive end shaft extensions
- 2-part yellow epoxy oxide primer (inside & outside)
- Gray epoxy paint and corrosion resistant hardware
- Reduced noise, vibration and mechanical tolerances
- Final test and vibration results shipped with motor
Typical applications include petro-chemical, pulp and paper plants, mines and other installations requiring premium efficient motors manufactured and tested to rigid standards for severe duty service.
