OEM#: ZDVSNM3665TNew OEM Original Outright
MOTOR, 5HP, 1800RPM, 3PH, 60HZ, L184TC, TENV, FOOT by BALDOR
Your price:
$6,844.33 each
OEM#: ZDVSNM3665TMOTOR, 5HP, 1800RPM, 3PH, 60HZ, L184TC, TENV, FOOT by BALDOR
New OEM Original Outright
Your price:
$6,844.33 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 5HP,1800RPM,3PH,60HZ,L184TC,TENV,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Technical Specs
P/N: ZDVSNM3665T Key Specs
Item
MOTOR, 5HP, 1800RPM, 3PH, 60HZ, L184TC, TENV, FOOT
OEM
BALDOR
OEM #
ZDVSNM3665T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Baldor Catalog Number
ZDVSNM3665T
Brg-De-Afbma
30BC02JP30X
Brg-Ode-Afbma
25BC03JP30X
Constant-Torq-Hertz
41.66736111
Country of Origin
USA
Dimension C (in)
16.19
Drive End Flange
C-Face
Duty
Continuous
Enclosure
TENV
Enclosure Type
Totally Enclosed
Frame
184TC
Horsepower
5
Insulation Class
F
Is_Motor
Yes
Magnetizing-Current
5.6/2.8
Maximum Motor Horsepower
5
Maximum RPM
6200
Motor Rpm 60Hz
1750
Motor-Base-Amps
12.8/6.4
Motor-Base-Hp
5
Motor-Base-Hz
60
Motor-Base-Rpm
1755
Motor-Base-Volts
230/460
Motor-Max-Amps
11.8/5.9
Motor-Max-Hz
90
Motor-Max-Rpm
2630
Motor-Max-Volts
230/460
Phase
3
Poles
4
RPM Range
1701-1800
Reliance Number
E02619A A 001
Rotor Inertia
0.48
Rpm
1750
Service Factor
1
Spec. Number
P18G1234
Temp. Code
2
Type
P
Weight
151
Baldor-Reliance Motor, 5HP,1800RPM,3PH,60HZ,L184TC,TENV,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
