OEM#: ZDVSM4104TNew OEM Original Outright
MOTOR, 30HP, 1800RPM, 3PH, 60HZ, 286TC, TEFC, FOOT by BALDOR
Your price:
$13,175.46 each
OEM#: ZDVSM4104TMOTOR, 30HP, 1800RPM, 3PH, 60HZ, 286TC, TEFC, FOOT by BALDOR
New OEM Original Outright
Your price:
$13,175.46 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 30HP,1800RPM,3PH,60HZ,286TC,TEFC,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Technical Specs
P/N: ZDVSM4104T Key Specs
Item
MOTOR, 30HP, 1800RPM, 3PH, 60HZ, 286TC, TEFC, FOOT
OEM
BALDOR
OEM #
ZDVSM4104T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
ZDVSM4104T
Brg-De-Afbma
50BC03JP30X
Brg-Ode-Afbma
50BC03JP30X
C-Dimension Inches
27.44
Constant-Torq-Hertz
1000 1
Country of Origin
USA
Drive End Flange
C-Face
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
286TC
Horsepower
30
Insulation Class
F
Is_Motor
Yes
Magnetizing-Current
30.8/15.4
Maximum-Rpm
5400
Motor Rpm 60Hz
1770
Motor-Base-Amps
76.2/38.1
Motor-Base-Hp
30
Motor-Base-Hz
60
Motor-Base-Rpm
1775
Motor-Base-Volts
230/460
Motor-Max-Amps
70.6/35.3
Motor-Max-Hp
30
Motor-Max-Hz
90
Motor-Max-Rpm
2660
Motor-Max-Volts
230/460
Phase
3
Poles
4
Reliance Number
W00980A A 003
Rotor-Inertia
3.7
Rpm
1770
Rpm Range
1701-1800
Service Factor
1
Spec. Number
P28G3216
Temp. Code
2
Type
P
Weight
450
Baldor-Reliance Motor, 30HP,1800RPM,3PH,60HZ,286TC,TEFC,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
