OEM#: VEWDM3558TNew OEM Original Outright

MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR

Your price:
$2,114.24 eachReady to ship
HomeBALDORVEWDM3558T
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR

OEM#: VEWDM3558T
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$2,114.24 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 2HP,1725RPM,3PH,60HZ,145TC,3532M,TEFC,F1

Features:
  • Moisture sealant on bolt heads, between frame and endplates
  • Neoprene gaskets
  • Double sealed bearings
  • Forsheda® running contact v-ring slinger
  • Stainless steel shaft
  • Electrostatically applied epoxy finish
  • Class F insulation
  • Tropicalized
Typical Applications:
Food processing and other applications where motor is regularly exposed to high pressure wash down.

Technical Specs
P/N: VEWDM3558T Key Specs
Item
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1
OEM
BALDOR
OEM #
VEWDM3558T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
VEWDM3558T
Bearing-Opp-Drive-End
6203
C-Dimension Inches
14.18
Country of Origin
USA
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6-5.8/2.9
Frame
145TC
Hertz
60
Horsepower
2
Is_Motor
Yes
Motor Rpm 60Hz
1755
Mounting
C-Face Footless
Phase
3
Poles
4
Rpm
1755
Rpm Range
1701-1800
Service Factor
1.15
Voltage
208-230/460
Weight
48
Baldor-Reliance Motor, 2HP,1725RPM,3PH,60HZ,145TC,3532M,TEFC,F1

Features:
  • Moisture sealant on bolt heads, between frame and endplates
  • Neoprene gaskets
  • Double sealed bearings
  • Forsheda® running contact v-ring slinger
  • Stainless steel shaft
  • Electrostatically applied epoxy finish
  • Class F insulation
  • Tropicalized
Typical Applications:
Food processing and other applications where motor is regularly exposed to high pressure wash down.
