OEM#: VEL11307New OEM Original Outright
MOTOR 3/4 HP 1 SPEED 10.2/5.1 FULL LOAD by BALDOR
Your price:
$1,190.85 each
OEM#: VEL11307MOTOR 3/4 HP 1 SPEED 10.2/5.1 FULL LOAD by BALDOR
New OEM Original Outright
Your price:
$1,190.85 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: VEL11307 Key Specs
Item
MOTOR 3/4 HP 1 SPEED 10.2/5.1 FULL LOAD
OEM
BALDOR
OEM #
VEL11307
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC031A
Country of Origin
USA
Duty
Continuous
Frame
56C
Full Load Amps
10.2/5.1
HP
3/4
Hz
60
Includes
Conduit Box
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
11 23/64 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Face
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
81.8 %
Number of Speeds
1
Overall Length
13-1/4 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL, CSA
Voltage
115/230
