OEM#: L3501-50New OEM Original Outright
MOTOR, .33HP, MOTOR-RPMRPM, 1PH, 50HZ, 56, 3418L, TEF by BALDOR
Your price:
$775.59 each
OEM#: L3501-50MOTOR, .33HP, MOTOR-RPMRPM, 1PH, 50HZ, 56, 3418L, TEF by BALDOR
New OEM Original Outright
Your price:
$775.59 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .33HP,MOTOR-RPMRPM,1PH,50HZ,56,3418L,TEF
Features:
Suitable for a wide variety of applications where only 50 hertz power is available. Motors are designed to be used at rated voltages with tolerance of +/-½ 15% on voltage.
Features:
- Windings tied each end at every slot for rigidity
- Ball bearings
- High temperature insulation
- Copper windings
Suitable for a wide variety of applications where only 50 hertz power is available. Motors are designed to be used at rated voltages with tolerance of +/-½ 15% on voltage.
Technical Specs
P/N: L3501-50 Key Specs
Item
MOTOR, .33HP, MOTOR-RPMRPM, 1PH, 50HZ, 56, 3418L, TEF
OEM
BALDOR
OEM #
L3501-50
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.35
Country of Origin
USA
Design Code
N
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6.4/3.2
Fl Efficiency
59
Frame
56
Hertz
50
Horsepower
1/3
Insulation Class
F
Is_Motor
Yes
Kva-Code
L
Motor Rpm 50Hz
1425
Mounting
Rigid
Nameplate Rpm
1425
Phase
1
Poles
4
Power-Factor
60
Rpm Range
1401-1500
Service Factor
1.35
Spec. Number
34C61W120
Voltage
110/220
Weight
25
Baldor-Reliance Motor, .33HP,MOTOR-RPMRPM,1PH,50HZ,56,3418L,TEF
