OEM#: KM3454New OEM Original Outright

ELECTRIC MOTORS, .25HP, 1725RPM, 3PH, 60HZ, 56C, 3410M, TEFC, F1 by BALDOR

Your price:
$548.38 eachReady to ship
HomeBALDORKM3454
ELECTRIC MOTORS, .25HP, 1725RPM, 3PH, 60HZ, 56C, 3410M, TEFC, F1 by BALDOR
ELECTRIC MOTORS, .25HP, 1725RPM, 3PH, 60HZ, 56C, 3410M, TEFC, F1 by BALDOR

OEM#: KM3454
ELECTRIC MOTORS, .25HP, 1725RPM, 3PH, 60HZ, 56C, 3410M, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$548.38 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .25HP,1725RPM,3PH,60HZ,56C,3410M,TEFC,F1

Features:
  • Ball bearings
  • Locked drive end bearing
  • Heavy gauge steel frame
Typical Applications:
Pumps, fans, conveyors, machine tools, gear reducers.

Technical Specs
P/N: KM3454 Key Specs
Item
ELECTRIC MOTORS, .25HP, 1725RPM, 3PH, 60HZ, 56C, 3410M, TEFC, F1
OEM
BALDOR
OEM #
KM3454
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
1.7
Ambient Temp C
40
Bearing-Drive-End
6203
Bearing-Opp-Drive-End
6203
C-Dimension Inches
11.35
Country of Origin
USA
Design Code
B
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
1.3/.65
Fl Efficiency
64
Frame
56C
Hertz
60
Horsepower
1/4
Insulation Class
B
Is_Motor
Yes
Kva-Code
L
Motor Rpm 60Hz
1725
Mounting
C-Face Footless
Nameplate Rpm
1725
Phase
3
Poles
4
Power-Factor
56
Rpm Range
1701-1800
Service Factor
1.35
Spec. Number
34A63-895
Voltage
230/460
Weight
19
Baldor-Reliance Motor, .25HP,1725RPM,3PH,60HZ,56C,3410M,TEFC,F1

Features:
  • Ball bearings
  • Locked drive end bearing
  • Heavy gauge steel frame
Typical Applications:
Pumps, fans, conveyors, machine tools, gear reducers.
