OEM#: JPL1409TNew OEM Original Outright

MOTOR, 5HP, 3500RPM, 1PH, 60HZ, 184JP, 3634LC, OPEN, F by BALDOR

Your price:
$2,522.59 eachReady to ship
HomeBALDORJPL1409T
MOTOR, 5HP, 3500RPM, 1PH, 60HZ, 184JP, 3634LC, OPEN, F by BALDOR
MOTOR, 5HP, 3500RPM, 1PH, 60HZ, 184JP, 3634LC, OPEN, F by BALDOR

OEM#: JPL1409T
MOTOR, 5HP, 3500RPM, 1PH, 60HZ, 184JP, 3634LC, OPEN, F by BALDOR

New OEM Original Outright
Your price:
$2,522.59 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 5HP,3500RPM,1PH,60HZ,184JP,3634LC,OPEN,F

Features:
  • Heavy gauge steel frame construction
  • Corrosion resistant finish
  • Ball bearings
  • Suitable for mounting in any position
Typical Applications:
Many pumping systems where only single phase power is available.

Technical Specs
P/N: JPL1409T Key Specs
Item
MOTOR, 5HP, 3500RPM, 1PH, 60HZ, 184JP, 3634LC, OPEN, F
OEM
BALDOR
OEM #
JPL1409T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
23
Ambient Temperature (°C)
40
Bearing Drive End
6207
Bearing Opposite Drive End
6205
Country of Origin
USA
Design Code
L
Dimension C (in)
19.57
Drive End Flange
C-Face
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Frame
184JP
Full Load Amps
21.5
Full Load Efficiency
80
Hertz
60
Horsepower
5
Insulation Class
F
Is_Motor
Yes
Kva-Code
H
Motor Rpm 60Hz
3500
Mounting
Rigid
Phase
1
Poles
2
Power-Factor
96
RPM Range
3001-3600
Rpm
3500
Service Factor
1.15
Spec. Number
36E774W925G1
Voltage
230
Weight
88
Baldor-Reliance Motor, 5HP,3500RPM,1PH,60HZ,184JP,3634LC,OPEN,F

Features:
  • Heavy gauge steel frame construction
  • Corrosion resistant finish
  • Ball bearings
  • Suitable for mounting in any position
Typical Applications:
Many pumping systems where only single phase power is available.
