OEM#: JML1406TNew OEM Original Outright

MOTOR, 3HP, 3450RPM, 1PH, 60HZ, 182JM, 3628L, OPEN, F1 by BALDOR

Your price:
$2,034.34 eachReady to ship
HomeBALDORJML1406T
MOTOR, 3HP, 3450RPM, 1PH, 60HZ, 182JM, 3628L, OPEN, F1 by BALDOR
MOTOR, 3HP, 3450RPM, 1PH, 60HZ, 182JM, 3628L, OPEN, F1 by BALDOR

OEM#: JML1406T
MOTOR, 3HP, 3450RPM, 1PH, 60HZ, 182JM, 3628L, OPEN, F1 by BALDOR

New OEM Original Outright
Your price:
$2,034.34 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 3HP,3450RPM,1PH,60HZ,182JM,3628L,OPEN,F1

Features:
  • Heavy gauge steel frame construction
  • Corrosion resistant finish
  • Ball bearings
  • Suitable for mounting in any position
Typical Applications:
Many pumping systems where only single phase power is available.

Technical Specs
P/N: JML1406T Key Specs
Item
MOTOR, 3HP, 3450RPM, 1PH, 60HZ, 182JM, 3628L, OPEN, F1
OEM
BALDOR
OEM #
JML1406T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
14.7
Ambient Temperature (°C)
40
Bearing Drive End
6207
Bearing Opposite Drive End
6205
Country of Origin
USA
Design Code
L
Dimension C (in)
16.5
Drive End Flange
C-Face
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Frame
182JM
Full Load Amps
28/14.7-14
Full Load Efficiency
78
Hertz
60
Horsepower
3
Insulation Class
B
Is Motor
Yes
Motor RPM 60 Hertz
3450
Mounting
Rigid
Phase
1
Poles
2
Power Factor
88
RPM
3450
RPM Range
3001-3600
Service Factor
1.15
Spec. Number
36G095-0115G1
Voltage
115/208-230
Weight
70
kVA-Code
G
Baldor-Reliance Motor, 3HP,3450RPM,1PH,60HZ,182JM,3628L,OPEN,F1

Features:
  • Heavy gauge steel frame construction
  • Corrosion resistant finish
  • Ball bearings
  • Suitable for mounting in any position
Typical Applications:
Many pumping systems where only single phase power is available.
