OEM#: IDVSM4400T-4New OEM Original Outright
MOTOR, 100HP, 1785RPM, 3PH, 60HZ, 405T, TEFC, FOOT by BALDOR
Your price:
$31,600.60 each
OEM#: IDVSM4400T-4MOTOR, 100HP, 1785RPM, 3PH, 60HZ, 405T, TEFC, FOOT by BALDOR
New OEM Original Outright
Your price:
$31,600.60 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 100HP,1785RPM,3PH,60HZ,405T,TEFC,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Technical Specs
P/N: IDVSM4400T-4 Key Specs
Item
MOTOR, 100HP, 1785RPM, 3PH, 60HZ, 405T, TEFC, FOOT
OEM
BALDOR
OEM #
IDVSM4400T-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Baldor Catalog Number
IDVSM4400T-4
Bearing Drive End (AFBMA standard)
80BC03J30X
Bearing Opposite Drive End (AFBMA standard)
80BC03J30X
Constant-Torq-Hertz
1000 1
Country of Origin
USA
Dimension C (in)
38.31
Drive End Flange
Standard
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
405T
Horsepower
100
Insulation Class
F
Is Motor
Yes
Magnetizing-Current
37.8
Maximum Motor Amps
112
Maximum Motor Hertz
90
Maximum Motor Horsepower
100
Maximum Motor RPM
2680
Maximum Motor Volts
460
Maximum RPM
3600
Motor Base Amps
115
Motor Base Hertz
60
Motor Base Horsepower
100
Motor Base RPM
1785
Motor Base Volts
460
Motor RPM 60 Hertz
1785
Phase
3
Poles
4
RPM
1785
RPM Range
1701-1800
Reliance Number
W06251A A 001
Rotor Inertia
26
Service Factor
1
Spec. Number
P40G3207
Temperature Code
2
Type
P
Weight
1,257.00
Baldor-Reliance Motor, 100HP,1785RPM,3PH,60HZ,405T,TEFC,FOOT,
Features:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Features:
- Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
- Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
- Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
- Continuous constant torque to zero speed
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
