OEM#: EM3710T-GNew OEM Original Outright
HVAC MOTOR, 3 PH, 7.5 HP, 230/460 V, 1770 RPM, TEFC, 213T FRAME by BALDOR
Your price:
$1,632.07 each $2,015.00 Savings: $382.93 (19%)
OEM#: EM3710T-GHVAC MOTOR, 3 PH, 7.5 HP, 230/460 V, 1770 RPM, TEFC, 213T FRAME by BALDOR
New OEM Original Outright
Your price:
$1,632.07 each
$2,015.00 Savings: $382.93 (19%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance HVAC Motor, EM3710T-G, 3 PH, 7.5 HP, 230/460 V, 1770 RPM, TEFC, 213T Frame
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
- Class H insulated with AEGIS shaft grounding ring installed internally
- Regreasable ball bearings
- Dynamically balanced rotors for reduced vibration and quiet operation
- Suitable for mounting in any position
- Meet or exceed NEMA Premium efficiencies
- Inverter Ready
- 3 year warranty
- Heating, ventilation and air conditioning blower and fan motors, pump motors, and other general purpose applications using an adjustable speed drive.
Technical Specs
P/N: EM3710T-G Key Specs
Item
HVAC MOTOR, 3 PH, 7.5 HP, 230/460 V, 1770 RPM, TEFC, 213T FRAME
OEM
BALDOR
OEM #
EM3710T-G
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Approvals, Certifications & Standards
CSA; CSA EEV; UR
Bearing Type
Ball
Design Code
A
Drive End Bearing Size
6307
Duty
Continuous
Enclosure Type
Totally Enclosed
Frame
213T
Frame Size
213T
Full Load Amps
9.5/20.0/19.0
Full Load Efficiency
91.7
Height (in)
16
Hertz
60
Horsepower
7 1/2
Insulation Class
H
Is Motor
Yes
Length (in)
26.5
Length Less Shaft (in)
21.5
Motor RPM 60 Hertz
1770
Mounting
Rigid
Opposite End Bearing
6206
Opposite End Bearing Size
6206
Overall Length
19.01
Phase
3
RPM Range
1701-1800
Rated RPM
1770
Rotation
CCW/CW
Service Factor
1.15
Shaft Diameter
1.375
Shaft Diameter (in)
1.125
Speeds
1
Thermal Protection
None
Voltage
230/460
Weight (lb)
135
Width (in)
16.5
Baldor-Reliance HVAC Motor, EM3710T-G, 3 PH, 7.5 HP, 230/460 V, 1770 RPM, TEFC, 213T Frame
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
- Class H insulated with AEGIS shaft grounding ring installed internally
- Regreasable ball bearings
- Dynamically balanced rotors for reduced vibration and quiet operation
- Suitable for mounting in any position
- Meet or exceed NEMA Premium efficiencies
- Inverter Ready
- 3 year warranty
- Heating, ventilation and air conditioning blower and fan motors, pump motors, and other general purpose applications using an adjustable speed drive.
