OEM#: EM3616T-5New OEM Original Outright

7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1 by BALDOR

Your price:
$2,226.92 eachReady to ship
HomeBALDOREM3616T5
7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1 by BALDOR
7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1 by BALDOR

OEM#: EM3616T-5
7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$2,226.92 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance, EM3616T-5, 7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available.

Technical Specs
P/N: EM3616T-5 Key Specs
Item
7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1
OEM
BALDOR
OEM #
EM3616T-5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6206
Bearing-Opp-Drive-End
6205
C-Dimension Inches
18.04
Country of Origin
USA
Design Code
A
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6.8
Fl Efficiency
89.5
Frame
184T
Hertz
60
Horsepower
7 1/2
Insulation Class
F
Is_Motor
Yes
Kva-Code
J
Motor Rpm 60Hz
3450
Mounting
Rigid
Nameplate Rpm
3450
Phase
3
Poles
2
Power-Factor
93
Rpm Range
3001-3600
Service Factor
1.15
Spec. Number
36A001X881H1
Voltage
575
Weight
96
Baldor-Reliance, EM3616T-5, 7.5HP, 3470RPM, 3PH, 60HZ, 575V, 184T, 3646M, TEFC, F1

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available.
