OEM#: EM3546T-8New OEM Original Outright
MOTOR, 1HP, 1765RPM, 3PH, 60HZ, 143T, 3524M, TEFC, F1 by BALDOR
Your price:
$1,395.75 each
OEM#: EM3546T-8MOTOR, 1HP, 1765RPM, 3PH, 60HZ, 143T, 3524M, TEFC, F1 by BALDOR
New OEM Original Outright
Your price:
$1,395.75 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 1HP,1765RPM,3PH,60HZ,143T,3524M,TEFC,F1
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EM3546T-8 Key Specs
Item
MOTOR, 1HP, 1765RPM, 3PH, 60HZ, 143T, 3524M, TEFC, F1
OEM
BALDOR
OEM #
EM3546T-8
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Bearing Drive End
6205
Bearing Opposite Drive End
6203
Country of Origin
USA
Design Code
B
Dimension C (in)
13.31
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
143T
Full Load Amps
3.5
Full Load Efficiency
85.5
Hertz
60
Horsepower
1
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
1760
Mounting
Rigid
Nameplate RPM
1760
Phase
3
Poles
4
Power Factor
71
RPM Range
1701-1800
Service Factor
1.15
Spec. Number
35AA001M848G1
Voltage
200
Weight
39
kVA-Code
L
Baldor-Reliance Motor, 1HP,1765RPM,3PH,60HZ,143T,3524M,TEFC,F1
