OEM#: EM3311TNew OEM Original Outright
MOTOR 3-PH 7-1/2 HP 1770 RPM 213T ODP by BALDOR
Your price:
$2,322.21 each
OEM#: EM3311TMOTOR 3-PH 7-1/2 HP 1770 RPM 213T ODP by BALDOR
New OEM Original Outright
Your price:
$2,322.21 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: EM3311T Key Specs
Item
MOTOR 3-PH 7-1/2 HP 1770 RPM 213T ODP
OEM
BALDOR
OEM #
EM3311T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
CSA, UL
CC Number
CC031A
Country of Origin
USA
Duty
Continuous
Frame
213T
Full Load Amps
20.4-19.4/9.7
Horsepower
7-1/2 hp
Hz
60
Insulation Class
F
Inverter Rated
Yes
Length Less Shaft
14 15/16 in
Maximum Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1770
Nominal Efficiency
91 %
Number of Speeds
1
Overall Length
16-5/16 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
1-3/8 in
Shaft Length
3-3/8 in
Voltage
230/460
