OEM#: EM2539T-5New OEM Original Outright

3-PHASE MOTOR, 40 HP, 1770 RPM, 324T FRAME, FOOT MOUNT, OPSB, 575 VOLTS by BALDOR

Your price:
$7,473.76 eachReady to ship
HomeBALDOREM2539T5
3-PHASE MOTOR, 40 HP, 1770 RPM, 324T FRAME, FOOT MOUNT, OPSB, 575 VOLTS by BALDOR
3-PHASE MOTOR, 40 HP, 1770 RPM, 324T FRAME, FOOT MOUNT, OPSB, 575 VOLTS by BALDOR

OEM#: EM2539T-5
3-PHASE MOTOR, 40 HP, 1770 RPM, 324T FRAME, FOOT MOUNT, OPSB, 575 VOLTS by BALDOR

New OEM Original Outright
Your price:
$7,473.76 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance 3-Phase Motor, EM2539T-5, 40 HP, 1770 RPM, 324T Frame, Foot Mount, OPSB, 575 Volts

Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.

Features
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Application(s)
  • Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available.
Technical Specs
P/N: EM2539T-5 Key Specs
Item
3-PHASE MOTOR, 40 HP, 1770 RPM, 324T FRAME, FOOT MOUNT, OPSB, 575 VOLTS
OEM
BALDOR
OEM #
EM2539T-5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6312
Bearing-Opp-Drive-End
6309
C-Dimension Inches
27.19
Country of Origin
USA
Design Code
A
Duty
Continuous
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Fl Amps
40
Fl Efficiency
94.1
Frame
324T
Hertz
60
Horsepower
40
Insulation Class
F
Is_Motor
Yes
Kva-Code
H
Motor Rpm 60Hz
1770
Mounting
Rigid
Nameplate Rpm
1770
Phase
3
Power-Factor
81
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
40J002X786G1
Type
200-575V Motor
Voltage
575
Baldor-Reliance 3-Phase Motor, EM2539T-5, 40 HP, 1770 RPM, 324T Frame, Foot Mount, OPSB, 575 Volts

Some general purpose applications require a motor that runs on 200 volt power. These 200 volt motors are stocked from 1 Hp to 50 Hp in TEFC, and 1 Hp to 100 Hp in ODP. Also available is an extensive line of 575 volt motors. The 575 volt motors are available in general purpose TEFC and ODP, Washdown, Severe Duty, IEEE-841, Explosion Proof, and Close-Coupled pump designs, in a variety of mounting configurations.

Features
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Application(s)
  • Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available.
