OEM#: EM2535T-GNew OEM Original Outright
HVAC MOTOR, 3 PH, 30 HP, 208-230/460 V, 1800 RPM, OPSB, 286T FRAME by BALDOR
Your price:
$3,984.22 each $4,599.00 Savings: $614.78 (13%)
OEM#: EM2535T-GHVAC MOTOR, 3 PH, 30 HP, 208-230/460 V, 1800 RPM, OPSB, 286T FRAME by BALDOR
New OEM Original Outright
Your price:
$3,984.22 each
$4,599.00 Savings: $614.78 (13%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance HVAC Motor, EM2535T-G, 3 PH, 30 HP, 208-230/460 V, 1800 RPM, OPSB, 286T Frame
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
- Class H insulated with AEGIS shaft grounding ring installed internally
- Regreasable ball bearings
- Dynamically balanced rotors for reduced vibration and quiet operation
- Suitable for mounting in any position
- Meet or exceed NEMA Premium efficiencies
- Inverter Ready
- 3 year warranty
- Heating, ventilation and air conditioning blower and fan motors,pump motors, and other general purpose applications using an adjustable speed drive.
Technical Specs
P/N: EM2535T-G Key Specs
Item
HVAC MOTOR, 3 PH, 30 HP, 208-230/460 V, 1800 RPM, OPSB, 286T FRAME
OEM
BALDOR
OEM #
EM2535T-G
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Approvals, Certifications & Standards
CSA; CSA EEV; UR
Bearing Type
Ball
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Frame
286T
Frame Size
286T
Full Load Amps
76.0/72.0/36.0
Full Load Efficiency
94.1
Height (in)
23.75
Hertz
60
Horsepower
30
Insulation Class
H
Is_Motor
Yes
Length (in)
31
Length Less Shaft Inches
31
Motor Rpm 60Hz
1800
Mounting
Rigid
Overall Length
26.06
Phase
3
RPM Range
1701-1800
Rated RPM
1800
Rotation
CCW/CW
Service Factor
1.15
Shaft Diameter
1.875
Shaft Diameter (in)
1.875
Speeds
1
Thermal Protection
None
Voltage
208-230/460
Weight (lb)
375
Width (in)
23.75
Baldor-Reliance HVAC Motor, EM2535T-G, 3 PH, 30 HP, 208-230/460 V, 1800 RPM, OPSB, 286T Frame
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
Baldor-Reliance's line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.
Features
- Class H insulated with AEGIS shaft grounding ring installed internally
- Regreasable ball bearings
- Dynamically balanced rotors for reduced vibration and quiet operation
- Suitable for mounting in any position
- Meet or exceed NEMA Premium efficiencies
- Inverter Ready
- 3 year warranty
- Heating, ventilation and air conditioning blower and fan motors,pump motors, and other general purpose applications using an adjustable speed drive.
