OEM#: EM2531TNew OEM Original Outright
MOTOR, 25HP, 1770RPM, 3PH, 60HZ, 284T, 4046M, OPSB, F1 by BALDOR
Your price:
$5,369.85 each
OEM#: EM2531TMOTOR, 25HP, 1770RPM, 3PH, 60HZ, 284T, 4046M, OPSB, F1 by BALDOR
New OEM Original Outright
Your price:
$5,369.85 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 25HP,1770RPM,3PH,60HZ,284T,4046M,OPSB,F1
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EM2531T Key Specs
Item
MOTOR, 25HP, 1770RPM, 3PH, 60HZ, 284T, 4046M, OPSB, F1
OEM
BALDOR
OEM #
EM2531T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Bearing Drive End
6311
Bearing Opposite Drive End
6309
Country of Origin
USA
Design Code
B
Dimension C (in)
23.81
Doe-Code
010A
Drive End Flange
Standard
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Frame
284T
Full Load Amps
58/29
Full Load Efficiency
93.6
Grease
POLYREX EM
Hertz
60
Horsepower
25
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
1760
Mounting
Rigid
Nameplate RPM
1760
Phase
3
Poles
4
Power Factor
86
RPM Range
1701-1800
Service Factor
1.15
Spec. Number
40G048W273G2
Voltage
230/460
Weight
330
kVA-Code
G
Baldor-Reliance Motor, 25HP,1770RPM,3PH,60HZ,284T,4046M,OPSB,F1
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
