OEM#: EM2516TNew OEM Original Outright
MOTOR, 25HP, 3525RPM, 3PH, 60HZ, 256T, 3940M, OPSB, F1 by BALDOR
Your price:
$4,946.91 each
OEM#: EM2516TMOTOR, 25HP, 3525RPM, 3PH, 60HZ, 256T, 3940M, OPSB, F1 by BALDOR
New OEM Original Outright
Your price:
$4,946.91 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 25HP,3525RPM,3PH,60HZ,256T,3940M,OPSB,F1
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EM2516T Key Specs
Item
MOTOR, 25HP, 3525RPM, 3PH, 60HZ, 256T, 3940M, OPSB, F1
OEM
BALDOR
OEM #
EM2516T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
62
Ambient Temperature (°C)
40
Bearing Drive End
6309
Bearing Opposite Drive End
6208
Country of Origin
USA
Design Code
B
Dimension C (in)
21.69
Doe-Code
010A
Drive End Flange
Standard
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Frame
256T
Full Load Amps
56/28
Full Load Efficiency
91.7
Hertz
60
Horsepower
25
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
3515
Mounting
Rigid
Nameplate RPM
3515
Phase
3
Poles
2
Power Factor
89
RPM Range
3001-3600
Service Factor
1.15
Spec. Number
39K057X424G1
Voltage
230/460
Weight
242
kVA-Code
G
Baldor-Reliance Motor, 25HP,3525RPM,3PH,60HZ,256T,3940M,OPSB,F1
Features:
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
