OEM#: EM2333TNew OEM Original Outright

MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 254T, 0936M, TEFC, F1 by BALDOR

Your price:
$3,242.22 eachReady to ship
HomeBALDOREM2333T
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 254T, 0936M, TEFC, F1 by BALDOR
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 254T, 0936M, TEFC, F1 by BALDOR

OEM#: EM2333T
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 254T, 0936M, TEFC, F1 by BALDOR

New OEM Original Outright
Your price:
$3,242.22 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 15HP,1765RPM,3PH,60HZ,254T,0936M,TEFC,F1

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available.

Technical Specs
P/N: EM2333T Key Specs
Item
MOTOR, 15HP, 1765RPM, 3PH, 60HZ, 254T, 0936M, TEFC, F1
OEM
BALDOR
OEM #
EM2333T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
38.9
Ambient Temperature (°C)
40
Bearing Drive End
6309
Bearing Opposite Drive End
6208
Country of Origin
USA
Design Code
B
Dimension C (in)
23.16
Doe-Code
010A
Drive End Flange
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
254T
Full Load Amps
37/18.5
Full Load Efficiency
92.4
Hertz
60
Horsepower
15
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
1765
Mounting
Rigid
Nameplate RPM
1765
Phase
3
Poles
4
Power Factor
82
RPM Range
1701-1800
Service Factor
1.15
Voltage
230/460
Weight
255
kVA-Code
H
Baldor-Reliance Motor, 15HP,1765RPM,3PH,60HZ,254T,0936M,TEFC,F1

Features:
  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
Typical Applications:
Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available.
