OEM#: ECP84110T-4New OEM Original Outright
SEVERE DUTY MOTOR, 3 PH, 40 HP, 460 V, 1770 RPM, TEFC, 324T FRAME by BALDOR
Your price:
$10,989.03 each
OEM#: ECP84110T-4SEVERE DUTY MOTOR, 3 PH, 40 HP, 460 V, 1770 RPM, TEFC, 324T FRAME by BALDOR
New OEM Original Outright
Your price:
$10,989.03 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Severe Duty Motor, ECP84110T-4, 3 PH, 40 HP, 460 V, 1770 RPM, TEFC, 324T Frame
Severe Duty motors are available from 1 HP to 700 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions. A few typical applications which might require these types of motors include petro-chemical plants, mines, foundries, pulp and paper plants, waste management facilities, rock crushers, and chemical plants.
Features
Severe Duty motors are available from 1 HP to 700 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions. A few typical applications which might require these types of motors include petro-chemical plants, mines, foundries, pulp and paper plants, waste management facilities, rock crushers, and chemical plants.
Features
- Designed and manufactured and tested to exceed the IEEE 841-1994 standards for severe duty TEFC induction motors
- Premium efficiency copper windings using Baldor-Reliance ISR (Inverter Spike Resistant)® magnet wire comply with CEE efficiency guidelines
- Inpro Seal® on fan and drive end shaft extensions
- 2-part yellow epoxy oxide primer (inside & outside)
- Gray epoxy paint and corrosion resistant hardware
- Reduced noise, vibration and mechanical tolerances
- Final test and vibration results shipped with motor
- Typical applications include petro-chemical, pulp and paper plants, mines and other installations requiring premium efficient motors manufactured and tested to rigid standards for severe duty service.
Technical Specs
P/N: ECP84110T-4 Key Specs
Item
SEVERE DUTY MOTOR, 3 PH, 40 HP, 460 V, 1770 RPM, TEFC, 324T FRAME
OEM
BALDOR
OEM #
ECP84110T-4
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
ECP84110T-4
Bearing-Drive-End
6312
C-Dimension Inches
30.53
Country of Origin
USA
Design Code
B
Doe-Code
010A
Duty
Continuous
Efficiency-2
93
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
46
Fl Efficiency
94.1
Frame
324T
Grease
POLYREX EM
Hertz
60
Horsepower
40
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Motor Rpm 60Hz
1770
Opposite End Bearing
6312
Phase
3
Power-Factor
85
Rpm
1770
Rpm Range
1701-1800
Service Factor
1.15
Spec. Number
12E599Y570
Type
Severe Duty Motor
Voltage
460
Baldor-Reliance Severe Duty Motor, ECP84110T-4, 3 PH, 40 HP, 460 V, 1770 RPM, TEFC, 324T Frame
