OEM#: ECP4310TNew OEM Original Outright

MOTOR, 60HP, 3560RPM, 3PH, 60HZ, 364TS, TEFC, FOOT by BALDOR

Your price:
$17,169.76 eachReady to ship
HomeBALDORECP4310T
MOTOR, 60HP, 3560RPM, 3PH, 60HZ, 364TS, TEFC, FOOT by BALDOR
MOTOR, 60HP, 3560RPM, 3PH, 60HZ, 364TS, TEFC, FOOT by BALDOR

OEM#: ECP4310T
MOTOR, 60HP, 3560RPM, 3PH, 60HZ, 364TS, TEFC, FOOT by BALDOR

New OEM Original Outright
Your price:
$17,169.76 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 60HP,3560RPM,3PH,60HZ,364TS,TEFC,FOOT,

Features:
  • 1.15 Service Factor
  • Corrosion resistant epoxy finish
  • Regreasable ball bearings
  • Oversized rotatable cast iron conduit box
  • Forsheda® shaft seal
  • Moisture resistant copper windings
  • Class F insulation
  • Stainless steel nameplate and corrosion resistant harware
  • Tropicalized
Typical Applications:
Typical applications include petro-chemical plants, mines, foundries, pulp and paper plants, waste management facilities, chemical plants, tropical climates and other processing industry applications requiring protection against corrosion caused by severe environmental operating conditions.

Technical Specs
P/N: ECP4310T Key Specs
Item
MOTOR, 60HP, 3560RPM, 3PH, 60HZ, 364TS, TEFC, FOOT
OEM
BALDOR
OEM #
ECP4310T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6313
Brg-De-Afbma
65BC03J30X
Brg-Ode-Afbma
65BC03J30X
C-Dimension Inches
31.31
Country of Origin
USA
Design Code
B
Drive End Flange
Standard
Duty
Continuous
Efficiency-1
95.4
Efficiency-2
94.5
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
130/65.1
Fl Efficiency
95
Frame
364TS
Hertz
60
Horsepower
60
Insulation Class
F
Is_Motor
Yes
Kva-Code
F
Motor Rpm 60Hz
3560
Opposite End Bearing
6313
Phase
3
Poles
2
Power-Factor
91
Power-Factor-Correction Capac
5
Rpm
3560
Rpm Range
3001-3600
Service Factor
1.15
Spec. Number
P36G401
Type
P
Voltage
230/460
Baldor-Reliance Motor, 60HP,3560RPM,3PH,60HZ,364TS,TEFC,FOOT,
