OEM#: DMG2315New OEM Original Outright
LIFTING MAGNET MOTOR, 15 HP, 1750 RPM, DPFG, 259AT FRAME by BALDOR
Your price:
$28,859.03 each
OEM#: DMG2315LIFTING MAGNET MOTOR, 15 HP, 1750 RPM, DPFG, 259AT FRAME by BALDOR
New OEM Original Outright
Your price:
$28,859.03 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Lifting Magnet Motor, DMG2315, 15 HP, 1750 RPM, DPFG, 259AT Frame
Baldor-Reliance Lifting Magnet Generators provide power for lifting electro-magnets used in scrap and bulk metal handling facilities. Horizontal motors may be belted from the diesel engine or the motors with C-faces may be coupled to the PTO drive of the crane.
Features
Baldor-Reliance Lifting Magnet Generators provide power for lifting electro-magnets used in scrap and bulk metal handling facilities. Horizontal motors may be belted from the diesel engine or the motors with C-faces may be coupled to the PTO drive of the crane.
Features
- Heavy duty steel frame
- Cast iron endplates
- Class H insulation with Class F temperature rise
- Precision brush holders
- Constant force brush springs
- Double sealed ball bearings
- Compound wound with drooping voltage characteristics
- DPFG enclosure
- Weather resistant paint
- F-2 conduit box
- Crane mounted lifting magnets for recyclers and steel mills.
Technical Specs
P/N: DMG2315 Key Specs
Item
LIFTING MAGNET MOTOR, 15 HP, 1750 RPM, DPFG, 259AT FRAME
OEM
BALDOR
OEM #
DMG2315
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Armature Voltage
230
Baldor Catalog Number
DMG2315
Country of Origin
USA
Drive End Bearing Size
6209
Enclosure
DPFG
Enclosure Type
Open/Drip Proof
Field Voltage
230
Frame
259AT
Frame Size
259AT
Full Load Amps - Armature
65
Full Load Amps - Field
1.3
Horsepower
15
Insulation Class
F
Motor Rpm 60Hz
1750
Mounting
Rigid
Opposite End Bearing
6207
Rpm
1750
Rpm Range
1701-1800
Service Factor
1
Specification Number
92A112-0963
Type
Lifting Magnet Motor
Baldor-Reliance Lifting Magnet Motor, DMG2315, 15 HP, 1750 RPM, DPFG, 259AT Frame
Baldor-Reliance Lifting Magnet Generators provide power for lifting electro-magnets used in scrap and bulk metal handling facilities. Horizontal motors may be belted from the diesel engine or the motors with C-faces may be coupled to the PTO drive of the crane.
Features
Baldor-Reliance Lifting Magnet Generators provide power for lifting electro-magnets used in scrap and bulk metal handling facilities. Horizontal motors may be belted from the diesel engine or the motors with C-faces may be coupled to the PTO drive of the crane.
Features
- Heavy duty steel frame
- Cast iron endplates
- Class H insulation with Class F temperature rise
- Precision brush holders
- Constant force brush springs
- Double sealed ball bearings
- Compound wound with drooping voltage characteristics
- DPFG enclosure
- Weather resistant paint
- F-2 conduit box
- Crane mounted lifting magnets for recyclers and steel mills.
