OEM#: CHM365ANew OEM Original Outright

MOTOR, .5HP, 1140RPM, 3PH, 60HZ, 56Z, 1718M, TEAO, F1 by BALDOR

Your price:
$789.00 eachReady to ship
HomeBALDORCHM365A
MOTOR, .5HP, 1140RPM, 3PH, 60HZ, 56Z, 1718M, TEAO, F1 by BALDOR
MOTOR, .5HP, 1140RPM, 3PH, 60HZ, 56Z, 1718M, TEAO, F1 by BALDOR

OEM#: CHM365A
MOTOR, .5HP, 1140RPM, 3PH, 60HZ, 56Z, 1718M, TEAO, F1 by BALDOR

New OEM Original Outright
Your price:
$789.00 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Motor, .5HP,1140RPM,3PH,60HZ,56Z,1718M,TEAO,F1

Features:
  • Automatic thermal overload
  • Ball bearings
  • Extended thru-bolts
  • Resilient cushion rings
  • Reversible rotation
  • Rugged steel frame
  • Suitable for mounting in any position
  • Terminal panel with quick connections on single phase
Typical Applications:
Air handling fans, Confinement houses, Exhaust fans, Unit heaters, and other applications having moderate starting loads

Technical Specs
P/N: CHM365A Key Specs
Item
MOTOR, .5HP, 1140RPM, 3PH, 60HZ, 56Z, 1718M, TEAO, F1
OEM
BALDOR
OEM #
CHM365A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
208V Amps
2.4
Ambient Temp C
60
Baldor Catalog Number
CHM365A
C-Dimension Inches
12.21
Country of Origin
USA
Design Code
B
Drive End Flange
Standard
Enclosure
TEAO
Enclosure Type
Totally Enclosed
Fl Amps
2.2/1.1
Fl Efficiency
72
Frame
56Z
Hertz
60
Horsepower
1/2
Insulation Class
B
Kva-Code
J
Motor Rpm 60Hz
1140
Mounting
Resilient Base
Phase
3
Poles
6
Rpm
1140
Rpm Range
1101-1200
Service Factor
1.25
Service-Factor-Amps
2.4/1.2
Spec. Number
17K039W467
Thermal-Select
N
Voltage
230/460
Weight
25
Baldor-Reliance Motor, .5HP,1140RPM,3PH,60HZ,56Z,1718M,TEAO,F1

Features:
  • Automatic thermal overload
  • Ball bearings
  • Extended thru-bolts
  • Resilient cushion rings
  • Reversible rotation
  • Rugged steel frame
  • Suitable for mounting in any position
  • Terminal panel with quick connections on single phase
Typical Applications:
Air handling fans, Confinement houses, Exhaust fans, Unit heaters, and other applications having moderate starting loads
