OEM#: CFSWDM3711T-ENew OEM Original Outright
FOOD SAFE, IP69, 10HP, 3500RPM, 3PH, 60HZ, 215TC, 3744M, TEFC, F by BALDOR
Your price:
$6,452.27 each
OEM#: CFSWDM3711T-EFOOD SAFE, IP69, 10HP, 3500RPM, 3PH, 60HZ, 215TC, 3744M, TEFC, F by BALDOR
New OEM Original Outright
Your price:
$6,452.27 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor CFSWDM3711T-E, Food Safe, IP69, 10HP, 3500RPM, 3PH, 60HZ, 215TC, 3744M, TEFC, F
Baldor-Reliance Food safe IP69 motors are designed to perform reliably- at maximum efficiency- around the clock and be effectively cleaned to a hygienic level to ensure uncompromised food safety.
Stainless Steel
Encapsulation/Potted Leads
Shaft Seals
Rotatable Conduit Box
Baldor-Reliance Food safe IP69 motors are designed to perform reliably- at maximum efficiency- around the clock and be effectively cleaned to a hygienic level to ensure uncompromised food safety.
Stainless Steel
- An all stainless-steel construction safeguards against corrosion to avoid costly downtime and repairs.
Encapsulation/Potted Leads
- Hardened epoxy resin completely encapsulates the windings for an additional layer of internal protection against water and humidity. The encapsulation extends into the conduit box to prevent moisture from entering the winding.
Shaft Seals
- Our two-barrier mechanical seal prevents water from entering at the shaft extension of the motor. The viton material is chemical resistant, withstands high temperature, and direct spray.
Rotatable Conduit Box
- The middle portion of our 3-piece conduit box can be rotated 360 degrees (at 90 degree increments) to rotate the lead opening in the direction you need it.
Technical Specs
P/N: CFSWDM3711T-E Key Specs
Item
FOOD SAFE, IP69, 10HP, 3500RPM, 3PH, 60HZ, 215TC, 3744M, TEFC, F
OEM
BALDOR
OEM #
CFSWDM3711T-E
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Approvals
UR, CSA
Baldor Catalog Number
CFSWDM3711T-E
Bearing-Drive-End
Sealed Bearing
Country of Origin
USA
Design
A
Duty
Continuous
Efficiency
0.917
Efficiency Type
Premium
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
10.6
Frame
215TC
Hertz
60
Horsepower
10
Is_Motor
Yes
Material
Stainless Steel
Mounting
Face and Foot
Phase
3
Rotation
Any
Rpm
3600
Rpm Range
3001-3600
Service Factor
1.15
Shaft Diameter
1.375 in
Shaft Length
3.375
Thermal Protection
None
Voltage
230/460
Weight
149
Baldor CFSWDM3711T-E, Food Safe, IP69, 10HP, 3500RPM, 3PH, 60HZ, 215TC, 3744M, TEFC, F
Baldor-Reliance Food safe IP69 motors are designed to perform reliably- at maximum efficiency- around the clock and be effectively cleaned to a hygienic level to ensure uncompromised food safety.
Stainless Steel
Encapsulation/Potted Leads
Shaft Seals
Rotatable Conduit Box
Baldor-Reliance Food safe IP69 motors are designed to perform reliably- at maximum efficiency- around the clock and be effectively cleaned to a hygienic level to ensure uncompromised food safety.
Stainless Steel
- An all stainless-steel construction safeguards against corrosion to avoid costly downtime and repairs.
Encapsulation/Potted Leads
- Hardened epoxy resin completely encapsulates the windings for an additional layer of internal protection against water and humidity. The encapsulation extends into the conduit box to prevent moisture from entering the winding.
Shaft Seals
- Our two-barrier mechanical seal prevents water from entering at the shaft extension of the motor. The viton material is chemical resistant, withstands high temperature, and direct spray.
Rotatable Conduit Box
- The middle portion of our 3-piece conduit box can be rotated 360 degrees (at 90 degree increments) to rotate the lead opening in the direction you need it.
