OEM#: CEM3314TNew OEM Original Outright
GENERAL PURPOSE MOTOR, 230/460 V, 15 HP, 3475 RPM, 3 PH, 215TC, OPSB by BALDOR
Your price:
$4,003.72 each
OEM#: CEM3314TGENERAL PURPOSE MOTOR, 230/460 V, 15 HP, 3475 RPM, 3 PH, 215TC, OPSB by BALDOR
New OEM Original Outright
Your price:
$4,003.72 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance General Purpose Motor, 230/460 V, 15 HP, 3475 RPM, 3 PH, 215TC, OPSB
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
Baldor-Reliance's extensive line of General Purpose motors are available in Open Drip-proof and TEFC construction in both single and three phase. Horsepower sizes available from stock range from 1/12 HP through 1500 HP. Designed for General purpose use means that these motors can be used in applications which include compressors, pumps, fans, conveyors, material handling, machine tools and many others.
Features
- Pressure cast aluminum end plates with ribbed design for rigidity
- Ball bearings
- Locked drive end bearing
- Heavy gauge steel frame
- Super-E motors have NEMA Premium efficiency
- 3 year warranty
- Pumps, fans, conveyors, machine tool, gear reducers.
Technical Specs
P/N: CEM3314T Key Specs
Item
GENERAL PURPOSE MOTOR, 230/460 V, 15 HP, 3475 RPM, 3 PH, 215TC, OPSB
OEM
BALDOR
OEM #
CEM3314T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Baldor Catalog Number
CEM3314T
Bearing Drive End
6307
Bearing Opposite Drive End
6206
Country of Origin
USA
Design Code
B
Dimension C (in)
17.06
Duty
Continuous
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Frame
215TC
Full Load Amps
35/17.5
Full Load Efficiency
90.2
Hertz
60
Horsepower
15
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
3475
Mounting
C-Face Rigid
Nameplate RPM
3475
Phase
3
Power Factor
89
RPM Range
3001-3600
Service Factor
1.15
Spec. Number
37B102S867G1
Type
General Purpose Motor
Voltage
230/460
kVA-Code
G
