OEM#: CEM31112New OEM Original Outright
.75HP 1800RPM 56CFRAME 3PH 208-230/460V, ODP, C-FACE RIGID, PREMIUM EFFICIENCY by BALDOR
Your price:
$1,043.34 each
OEM#: CEM31112.75HP 1800RPM 56CFRAME 3PH 208-230/460V, ODP, C-FACE RIGID, PREMIUM EFFICIENCY by BALDOR
New OEM Original Outright
Your price:
$1,043.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance CEM31112 .75HP 1800RPM 56C Frame 3PH 208-230/460V, ODP, C-Face Rigid, Premium Efficiency
Baldor-Reliance 3-Phase ODP motors are in accordance with the Small Motor Rule implemented by the Department of Energy. These motors feature copper windings, ball bearings, heavy duty steel and cast iron frames. Super-E® motors have NEMA Premium® Efficiency and a 3 year warranty.
Features:
Baldor-Reliance 3-Phase ODP motors are in accordance with the Small Motor Rule implemented by the Department of Energy. These motors feature copper windings, ball bearings, heavy duty steel and cast iron frames. Super-E® motors have NEMA Premium® Efficiency and a 3 year warranty.
Features:
Technical Specs
P/N: CEM31112 Key Specs
Item
.75HP 1800RPM 56CFRAME 3PH 208-230/460V, ODP, C-FACE RIGID, PREMIUM EFFICIENCY
OEM
BALDOR
OEM #
CEM31112
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature (°C)
40
Country of Origin
USA
Degree of Protection
IP22
Drive End Bearing Size
6205
Duty
Continuous
Efficiency Type
Premium
Enclosure
ODP
Enclosure Type
Open/Drip Proof
Frame
56C
Full Load Amps
2.1-2/1
Full Load Efficiency
81.1
Hertz
60
Horsepower
3/4
Insulation Class
F
Is Motor
Yes
Motor RPM 60 Hertz
1800
Mounting
C-Face Rigid
Nameplate RPM
1725
Opposite End Bearing Size
6203
Phase
3
Poles
4
Power Factor at Full Load
84
RPM Range
1701-1800
Service Factor
1.25
Voltage
208-230/460
Weight
35
Baldor-Reliance CEM31112 .75HP 1800RPM 56C Frame 3PH 208-230/460V, ODP, C-Face Rigid, Premium Efficiency
Baldor-Reliance 3-Phase ODP motors are in accordance with the Small Motor Rule implemented by the Department of Energy. These motors feature copper windings, ball bearings, heavy duty steel and cast iron frames. Super-E® motors have NEMA Premium® Efficiency and a 3 year warranty.
Features:
Baldor-Reliance 3-Phase ODP motors are in accordance with the Small Motor Rule implemented by the Department of Energy. These motors feature copper windings, ball bearings, heavy duty steel and cast iron frames. Super-E® motors have NEMA Premium® Efficiency and a 3 year warranty.
Features:
