OEM#: BC354New OEM Original Outright
FRACTIONAL HP DC SPEED CONTROL, NEMA 4X, 1 MAX HP by BALDOR
Your price:
$1,381.53 each
OEM#: BC354FRACTIONAL HP DC SPEED CONTROL, NEMA 4X, 1 MAX HP by BALDOR
New OEM Original Outright
Your price:
$1,381.53 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Fractional HP DC Speed Control, BC354, NEMA 4X, 1 Max HP
One-way DC controls are designed to operate permanent magnet or wound field motors. If the motor's rotation needs to be changed, the armature leads need to be reversed. Some NEMA 1 and NEMA 4X controls offer optional switched for reversal. Stopping of a motor with a one-way control should be done by dynamic braking, some controls offer the Forward-Brake-Reverse switch for this purpose too.
Features
One-way DC controls are designed to operate permanent magnet or wound field motors. If the motor's rotation needs to be changed, the armature leads need to be reversed. Some NEMA 1 and NEMA 4X controls offer optional switched for reversal. Stopping of a motor with a one-way control should be done by dynamic braking, some controls offer the Forward-Brake-Reverse switch for this purpose too.
Features
- Field power supply allows use with shunt wound DC motors as well as permanent magnet motors
- Adjustable accel, decel, current limit, IR comp, min and max speed
- Current limit indicating LED
- 5K speed pot for speed control
- Anti-demag circuit protects PM motors and helps protect the SCR power bridge against direct shorts
- Noise rejection circuit eliminates false starts and blown SCR's
- UL and cUL recognized
- Conveyors, mixers, packaging machinery and other applications requiring variable speed and constant torque.
Technical Specs
P/N: BC354 Key Specs
Item
FRACTIONAL HP DC SPEED CONTROL, NEMA 4X, 1 MAX HP
OEM
BALDOR
OEM #
BC354
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature Max
40
Ce Approval
Approved
Control Type
Analog
Cooling Type
Convection
Country of Origin
USA
Csa Approval
Approved
Cul Aproval
Approved
Depth Inches
5
Dynamic/Regenerative Braking
None
Enclosure Material
NEMA 4X
Enclosure Type
NEMA 4X
Height Inches
9.5
Hp
1
Input Phase - Rated
1
Input Voltage
115/230
Number Of Axis
1
Operator Interface
POT
Type
ANALOG
Ul
Approved
Width Inches
5.9
Baldor-Reliance Fractional HP DC Speed Control, BC354, NEMA 4X, 1 Max HP
One-way DC controls are designed to operate permanent magnet or wound field motors. If the motor's rotation needs to be changed, the armature leads need to be reversed. Some NEMA 1 and NEMA 4X controls offer optional switched for reversal. Stopping of a motor with a one-way control should be done by dynamic braking, some controls offer the Forward-Brake-Reverse switch for this purpose too.
Features
One-way DC controls are designed to operate permanent magnet or wound field motors. If the motor's rotation needs to be changed, the armature leads need to be reversed. Some NEMA 1 and NEMA 4X controls offer optional switched for reversal. Stopping of a motor with a one-way control should be done by dynamic braking, some controls offer the Forward-Brake-Reverse switch for this purpose too.
Features
- Field power supply allows use with shunt wound DC motors as well as permanent magnet motors
- Adjustable accel, decel, current limit, IR comp, min and max speed
- Current limit indicating LED
- 5K speed pot for speed control
- Anti-demag circuit protects PM motors and helps protect the SCR power bridge against direct shorts
- Noise rejection circuit eliminates false starts and blown SCR's
- UL and cUL recognized
- Conveyors, mixers, packaging machinery and other applications requiring variable speed and constant torque.
