OEM#: ACT-ELEMXRSSNew OEM Original Outright
ELECTRIC OPERATED DRUM PUMP, 1 HP MOTOR HP, 55 GAL FOR CONTAINER SIZE, 110V AC by Approved Vendor
Your price:
$3,770.33 each
OEM#: ACT-ELEMXRSSELECTRIC OPERATED DRUM PUMP, 1 HP MOTOR HP, 55 GAL FOR CONTAINER SIZE, 110V AC by Approved Vendor
New OEM Original Outright
Your price:
$3,770.33 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: ACT-ELEMXRSS Key Specs
Item
ELECTRIC OPERATED DRUM PUMP, 1 HP MOTOR HP, 55 GAL FOR CONTAINER SIZE, 110V AC
OEM
Approved Vendor
OEM #
ACT-ELEMXRSS
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Adapter Connection Type
MNPT
Adapter Material
Polyethylene
Bung Connection Diameter
2 in
Compatible Chemicals
Ammonia (Liquids), Calcium Chloride, Ethyl (Ethanol), Glycerin, Hexane, Methyl (Methanol), Sodium Bicarbonate (10%)
Cord Length
72 in
Country of Origin
Germany
Diesel Exhaust Fluid Compatible
No
Discharge Connection Type
Hose Barb
Discharge Tube Outlet ID
1-1/4 in
Discharge Tube Outlet OD
1-1/2 in
Display Quantity
1
Display Sell UOM
EA
Duty Cycle
Intermittent
Explosion Proof
No
Features
All In One Mixer for Chemicals That Need Blending or Have Sediments
Food Grade
No
For Container Size
55 gal
For Container Type
Drum
For Media Type
Ammonia, Calcium Chloride, Ethanol, Glycerin, Hexane, Methanol, Sodium Bicarbonate
For Use With
ACT-ELEMXRSS
Frequency (Hz)
60 Hz
Full Load Amps
5.2 A
Height Above Container
14 in
Housing Material - Pumps
Stainless Steel
Includes
Mixer, Motor, Pump Tube
Includes Bung Adapter
Yes
Includes Discharge Hose
No
Includes Suction Tube
Yes
Maximum Flow Rate
57 gpm
Maximum Fluid Temperature
250 °F
Maximum Head - Pumps
31 ft
Maximum Head Pressure
20 psi
Maximum Oil Flow
30 gpm
Maximum Outlet Pressure
85 psi
Maximum Viscosity
600 cps
Metered
No
Minimum Fluid Temperature
33 °F
Motor Enclosure
ODP
Motor Horsepower
1 hp
Motor RPM
10,500 RPM
Motor Type
Electric AC
Noise Level
85 db
Nominal Voltage
110V AC
Not Recommended Chemicals
Hydrochloric/Muriatic Acid (100%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%)
Nozzle Included
No
Number of Phases
1
Overall Length
48-1/2 in
Power Source
Electric
Pump Connection ID
1-1/2 in
Pump Connection OD
1-1/2 in
Pump Connection Type
Hose Barb
Pump Package Type
Basic Pump without Discharge Hose
Rated Voltage
120V AC
Runs Dry
No
Seal Material
PTFE
Self-Priming
Yes
Suction Tube ID
1-5/8 in
Suction Tube Length
39 in
Suction Tube Material
Stainless Steel
Suction Tube OD
1-3/8 in
Thermal Protection
Yes
Variable Speed
No
Wetted Materials
316 Stainless Steel, Carbon, Tefzel(R),Ceramic Oxide
