OEM#: 4353003800New OEM Original Outright
SHARPE VALVES PNEUMATICALLY ACTUATED TWO-WAY BALL VALVE, 3/4 IN SIZE, CARBON STEEL, FNPT X FNPT by Approved Vendor
Your price:
$1,798.70 each
OEM#: 4353003800SHARPE VALVES PNEUMATICALLY ACTUATED TWO-WAY BALL VALVE, 3/4 IN SIZE, CARBON STEEL, FNPT X FNPT by Approved Vendor
New OEM Original Outright
Your price:
$1,798.70 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4353003800 Key Specs
Item
SHARPE VALVES PNEUMATICALLY ACTUATED TWO-WAY BALL VALVE, 3/4 IN SIZE, CARBON STEEL, FNPT X FNPT
OEM
Approved Vendor
OEM #
4353003800
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
3-A Compliance
Not Rated
Actuator Air Pressure - Maximum
145 psi
Actuator Air Pressure - Minimum
40 psi
Actuator Operation
Air to Spring
Actuator Type
Single-Acting Spring Return
Ball Material
Stainless Steel
Ball Port Style
Full Port
Body Material
Carbon Steel
Coefficient of Volume (Cv)
35
Connection Gender - Side 1
Female
Connection Gender - Side 2
Female
Connection Size - Side 1
1/4 in
Connection Size - Side 2
1/4 in
Connection Type
FNPT x FNPT
Connection Type - Side 1
NPT
Connection Type - Side 2
NPT
Country of Origin
Taiwan
Fail Safe Position
Fail Closed
IP Rating
Not Rated
Included Mounting
ISO 5211 Actuator Mounting Pad
Max. Differential Pressure
145 psi
Max. Media Temperature
300 °F
Max. Pressure (CWP)
1,000 psi
Max. Pressure (Combustible Gas)
Not Rated
Max. Pressure (Steam)
100 psi
Media Temp. Range
0 °F to 300 °F
Min. Media Temperature
0 °F
NEMA Enclosure Rating
4X
Nominal Valve Size
3/4 in
Pilot Solenoid Voltage
Not Included
Seal Material
PTFE
Seat Material
PTFE
Special Features
Actuator Compatible
Standards
MSS SP-110
Stem Material
316 Stainless Steel
Stem Type
Adjustable, Blowout Resistant
Vacuum Service Rating
29 in Hg
Valve Body Style
Straight
Valve Construction
Three-Piece
Valve Deactivated State
Normally Closed (NC)
Valve Series
13
Valve Ways
2-Way
Vented Ball Valve
Vented
