OEM#: 00-275-MAXNew OEM Original Outright
ADAPTERS AND MAX HOLD PRESSURE MANOMETER by Anesthesia Associates
Your price:
$769.34 each
OEM#: 00-275-MAXADAPTERS AND MAX HOLD PRESSURE MANOMETER by Anesthesia Associates
New OEM Original Outright
Your price:
$769.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Pressure manometer with superior accuracy over the range of -40 to +80 CM H20 in a 2-1/2 IN diameter chrome plated case with 1/4 IN NPT Male bottom connection with front zero correcting screw. Comes with 15 MM Female Adapter (00-275-1), Neoprene elbow 15MM M x 22MM M/15MM F (00-452), and Harness (00-276). Used post-operatively for lung function evaluation. Also includes a resettable low friction pointer to capture max/min pressure reading with manual reset on dial face. A complete pressure monitoring and limiting system in one.
Features
- Max/ Min hold pointer, 90 deg elbow and harness included, front zero correction screw
Technical Specs
P/N: 00-275-MAX Key Specs
Item
ADAPTERS AND MAX HOLD PRESSURE MANOMETER
OEM
Anesthesia Associates
OEM #
00-275-MAX
Condition
New OEM Original
Returnable
Yes
Warranty
Mfr Warranty
Connection Size
15 MM
Connection Type
Female
Country of Origin
USA
Face Diameter
2.5 IN
Material of Construction
Chromed Brass, Neoprene
Scale
-40 to +80 cm H2O
Pressure manometer with superior accuracy over the range of -40 to +80 CM H20 in a 2-1/2 IN diameter chrome plated case with 1/4 IN NPT Male bottom connection with front zero correcting screw. Comes with 15 MM Female Adapter (00-275-1), Neoprene elbow 15MM M x 22MM M/15MM F (00-452), and Harness (00-276). Used post-operatively for lung function evaluation. Also includes a resettable low friction pointer to capture max/min pressure reading with manual reset on dial face. A complete pressure monitoring and limiting system in one.
