OEM#: BRV-830-1-1-TEFCNew OEM Original Outright

STEEL 30 DIA 45 L 46 H ROOF FAN W.MOTOR by Americraft Fan

Your price:
$4,379.81 eachReady to ship
HomeAmericraft FanBRV83011TEFC
STEEL 30 DIA 45 L 46 H ROOF FAN W.MOTOR by Americraft Fan
STEEL 30 DIA 45 L 46 H ROOF FAN W.MOTOR by Americraft Fan

OEM#: BRV-830-1-1-TEFC
STEEL 30 DIA 45 L 46 H ROOF FAN W.MOTOR by Americraft Fan

New OEM Original Outright
Your price:
$4,379.81 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: BRV-830-1-1-TEFC Key Specs
Item
STEEL 30 DIA 45 L 46 H ROOF FAN W.MOTOR
OEM
Americraft Fan
OEM #
BRV-830-1-1-TEFC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Assembled
Base Height (in)
45.25 in
Base Size - Roof Ventilators
45 in x 45 in
Bearing Type
Pillow Block
Blade Diameter
30 in
CFM @ 0.000 in SP
10668
CFM @ 0.125 in SP
9959
CFM @ 0.250 in SP
8626
CFM @ 0.375 in SP
6828
CFM @ 0.500 in SP
5184
CFM Range
10668-5184
Country of Origin
USA
Drive Package with Motor Included
Yes
Drive Type - Roof Ventilators
Belt Drive
Fan RPM
975
Housing Material
Heavy Gauge Steel
Item Type
Exhaust Ventilator
Maximum BHP
0.73 hp
Maximum Inlet Temperature (°F)
70 Degrees F
Maximum Operating Amps
6.4
Motor Horsepower
1 hp
Motor Horsepower Range
1 hp
Motor Hz
60
Mounting Location
Roof
Overall Diameter (in)
30 in
Overall Height (in)
45.25 in
Phase
1
Propeller Material
Steel
RPM Range
975
Shaft Diameter (Propeller End) (in)
0.875 in
Shaft Diameter (Sheave End) (in)
0.875 in
Sones @ 0.125 in SP @ 5 ft
18
Sones @ 0.250 in SP @ 5 ft
18
Speed Control
No
Speed Controllable
No
Voltage - Roof Ventilators
115V AC/230V AC
