Y UNION CHECK VALVE CPVC 1/2 SOCKET by Hayward
OEM#: YC20050SEU

New OEM Original Outright
Y UNION CHECK VALVE CPVC 1/2 SOCKET by Hayward
Y UNION CHECK VALVE CPVC 1/2 SOCKET by Hayward
Your price:
$242.18 / each
$245.00 Savings: $2.82 (1%)
Ship date will be provided after ordering
Asset Information

Estimated Ship Date is based on availability at time of order

Technical Specs

P/N: YC20050SEU Key Specs

Item
Y UNION CHECK VALVE CPVC 1/2 SOCKET
OEM
Hayward
OEM #
YC20050SEU
Condition
New OEM Original
Returnable
No
Application - Valves
General Purpose
Body Material - Valves
CPVC
Cap to Inlet Center
2-5/16 in
Connection Type - Check Valves
Socket x Socket
Cracking Pressure - Check Valves
1 psi
Flow - Valves
0.8 gpm
Flow Design
Single
Full Flow - Valves
Yes
Hex Size
1 in
Item - Check Valves
Check Valve
Length
6-41/64 in
Max Steam Pressure - Valves
Not Rated
Max Temperature - Valves
190 Degrees F
Max Water Pressure - Valves
150 psi @ 70 Degrees F
Mechanism and Body Design
Y True Union
Min Temperature - Valves
40 Degrees F
Mounting Orientation - Check Valves
Horizontal, Vertical
Overall Height
3-3/8 in
Pipe or Tube Size - Check Valves
1/2 in
Seal Material - Check Valves
EPDM
Seat Material - Check Valves
EPDM
Width
2-1/4 in
