OEM#: FG 12XL ECNew OEM Original Outright
STEEL 16 D 18 H 8 W INLINE DUCT FAN by Fantech
Your price:
$924.90 each
OEM#: FG 12XL ECSTEEL 16 D 18 H 8 W INLINE DUCT FAN by Fantech
New OEM Original Outright
Your price:
$924.90 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: FG 12XL EC Key Specs
Item
STEEL 16 D 18 H 8 W INLINE DUCT FAN
OEM
Fantech
OEM #
FG 12XL EC
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Ball
CFM @ 0.000-In. SP
805
CFM @ 0.125-In. SP
772
CFM @ 0.200-In. SP
780
CFM @ 0.250-In. SP
734
CFM @ 0.375-In. SP
692
CFM @ 0.400-In. SP
750
CFM @ 0.500-In. SP
650
CFM @ 0.600-In. SP
686
CFM @ 0.750-In. SP
556
CFM @ 0.800-In. SP
615
CFM @ 1.000-In. SP
474
CFM @ 1.500-In. SP
315
CFM @ Duct
750
Country of Origin
Germany
Fits Duct Dia.
12 in
Flange Width
1 13/16 in
Green Certification or Other Recognition
ENERGY STAR(R) Certified
Housing Dia.
16 in
Housing Finish
G90
Housing Material
Galvanized Steel
Hz
60
Inlet and Outlet Dia.
12 in
Length
9 3/16 in
Max. Amps
1.16 A
Max. Inlet Temp.
140 Degrees F
Max. Wattage
166
Motor Enclosure
44 IP
Motor RPM
2510
Mounting Position
Horizontal or Vertical
Number of Speeds
1
Phase
1
Speed Control
Yes
Standards
HVI, C-UL-US, cCSAus, AMCA
Voltage
120V
